- Made in the USA!
- Classic 8 hole mod window embossed design for added strength and durability
- Wheel and ring constructed out of heavy-duty USA made carbon steel
- Engineered to be one of the strongest wheels available.
- US made grade 8 zinc beadlock hardware with hardened steel PEM-nuts that along with captive washers can be replaced as needed...no more stripped wheels that are deemed worthless. Another industry best that are standard issue.
- Steel Beadlock Bolts = 1.25" length
- Available in both 15”, 16” and 17” diameters in a number of different widths.
Sizes & Specifications
| Size | Bolt Pattern | Offset | Weight (lb) | Part # |
|---|---|---|---|---|
| 15X10 | 5x114.3mm (5x4.5") | -44mm | 39.0 | RT8150012 |
| 15X10 | 5x139.7mm (5x5.5") | -44mm | 41.0 | RT8150055 |
| 15X10 | 6x139.7mm (6x5.5") | -44mm | 39.0 | RT8150060 |
| 15X8 | 5x114.3mm (5x4.5") | -19mm | 34.0 | RT8158012 |
| 15X8 | 5x139.7mm (5x5.5") | -19mm | 34.0 | RT8158055 |
| 15X8 | 6x139.7mm (6x5.5") | -19mm | 36.0 | RT8158060 |
| 16X8 | 5x114.3mm (5x4.5") | -19mm | 43.0 | RT8168012 |
| 16X8 | 5x139.7mm (5x5.5") | -19mm | 43.0 | RT8168055 |
| 16X8 | 6x139.7mm (6x5.5") | -19mm | 43.0 | RT8168060 |
| 16X8 | 8x165.1mm (8x6.5") | -19mm | 43.0 | RT8168080 |
| 17X8 | 5x114.3mm (5x4.5") | -25mm | 46.0 | RT8178012 |
| 17X8 | 5x127mm (5x5") | -25mm | 46.0 | RT8178050 |
| 17X8 | 5x139.7mm (5x5.5") | -25mm | 46.0 | RT8178055 |
| 17X8 | 6x139.7mm (6x5.5") | -25mm | 46.0 | RT8178060 |
| 17X8 | 8x165.1mm (8x6.5") | -25mm | 46.0 | RT8178080 |
| 17X9.5 | 5x114.3mm (5x4.5") | -44mm | 52.0 | RT8179512 |
| 17X9.5 | 5x127mm (5x5") | -44mm | 48.0 | RT8179550 |
| 17X9.5 | 5x139.7mm (5x5.5") | -44mm | 52.0 | RT8179555 |
| 17X9.5 | 6x139.7mm (6x5.5") | -44mm | 52.0 | RT8179560 |
| 17X9.5 | 8x165.1mm (8x6.5") | -44mm | 48.0 | RT8179580 |
Fitment shown by bolt pattern; confirm offset and brake clearance for your vehicle.
