- Modern split-spoke with design
- Flush face design accentuates wheel diameter
- Bolt on cap covers the lug area with contrasting embossed Raceline logo
- Constructed out of heavy duty A356 aluminum
- Available in both Gloss Black and Chrome
- Available in 18” to 22” diameters
- Passes or exceeds all DOT standard load ratings
- Hub centric fitments available for select vehicles
- Includes a Lifetime Structural Warranty (limitations may apply)
- The Official Wheel of SCORE International Off-Road Racing Series
Sizes & Specifications
| Size | Bolt Pattern | Offset | Weight (lb) | Part # |
|---|---|---|---|---|
| 22X9.5 | 5x115mm / 5x120mm | 15mm | 43.0 | 158B-229559+15 |
| 22X9.5 | 6x139.7mm (6x5.5") / 6x135mm | 15mm | 43.0 | 158B-229566+15 |
| 22X9.5 | 6x139.7mm (6x5.5") / 6x135mm | 35mm | 43.0 | 158B-229566+35 |
| 22X9.5 | 5x114.3mm (5x4.5") / 5x120mm | 35mm | 43.0 | 158B-229594+35 |
| 20X8.5 | 6x139.7mm (6x5.5") / 6x135mm | 15mm | 37.0 | 158B-28566+15 |
| 20X8.5 | 6x139.7mm (6x5.5") / 6x135mm | 35mm | 37.0 | 158B-28566+35 |
| 20X8.5 | 6x120mm / 6x139.7mm (6x5.5") | 15mm | 37.0 | 158B-28572+15 |
| 20X8.5 | 6x132mm / 6x120mm | 35mm | 37.0 | 158B-28574+35 |
| 20X8.5 | 5x110mm / 5x115mm | 15mm | 37.0 | 158B-28586+15 |
| 20X8.5 | 5x114.3mm (5x4.5") / 5x120mm | 35mm | 37.0 | 158B-28594+35 |
| 20X8.5 | 5x114.3mm (5x4.5") / 5x127mm (5x5") | 35mm | 37.0 | 158B-28596+35 |
| 18X8 | 6x139.7mm (6x5.5") / 6x135mm | 35mm | 31.0 | 158B-88066+35 |
| 18X8 | 6x132mm / 6x120mm | 35mm | 31.0 | 158B-88074+35 |
| 18X8 | 5x110mm / 5x114.3mm (5x4.5") | 35mm | 31.0 | 158B-88088+35 |
| 18X8 | 5x114.3mm (5x4.5") / 5x127mm (5x5") | 35mm | 31.0 | 158B-88096+35 |
Load rating(s): 2250 lb
Hub bore(s): 106.1, 72.62, 74.1, 74.6, 78.1 mm
Fitment shown by bolt pattern; confirm offset and brake clearance for your vehicle.
