- Clean off-road inspired spoke design
- Color matched caps with embossed Raceline logo for a seamless look
- Constructed out of heavy duty A356 aluminum
- Available in Satin Black, Titanium and Machined finish
- Available in 16” to 20” diameters for most 5, 6 and 8 lug trucks and CUV’s
- Passes or exceeds all DOT standard load ratings
- Hub centric fitments available for select vehicles
- Includes a Lifetime Structural Warranty (limitations may apply)
- The Official Wheel of Ultra 4 Racing, NORRA, MidAmerica Outdoors, Southern Rock Racing Series, Nor Cal Rock Racing and more
Sizes & Specifications
| Size | Bolt Pattern | Offset | Weight (lb) | Part # |
|---|---|---|---|---|
| 20X9 | 6x139.7mm (6x5.5") | 0mm | 39.0 | 958MC-29060-00 |
| 20X9 | 8x165.1mm (8x6.5") | 0mm | 43.0 | 958MC-29080-00 |
| 20X9 | 8x170mm | 0mm | 43.0 | 958MC-29081-00 |
| 16X8 | 6x139.7mm (6x5.5") | 0mm | 26.0 | 958MC-68060-00 |
| 17X8.5 | 5x127mm (5x5") | 0mm | 29.0 | 958MC-78550-00 |
| 17X8.5 | 5x150mm | 35mm | 29.0 | 958MC-78551+35 |
| 17X8.5 | 6x139.7mm (6x5.5") | 25mm | 958MC-78560+25 | |
| 17X8.5 | 6x139.7mm (6x5.5") | 35mm | 29.0 | 958MC-78560+35 |
| 17X8.5 | 6x139.7mm (6x5.5") | 0mm | 28.0 | 958MC-78560-00 |
| 17X8.5 | 6x135mm | 35mm | 29.0 | 958MC-78565+35 |
| 17X8.5 | 6x135mm | 0mm | 29.0 | 958MC-78565-00 |
| 17X8.5 | 8x165.1mm (8x6.5") | 0mm | 32.0 | 958MC-78580-00 |
| 17X8.5 | 8x170mm | 0mm | 32.0 | 958MC-78581-00 |
| 17X9 | 6x139.7mm (6x5.5") | -12mm | 29.0 | 958MC-79060-12 |
| 17X9 | 6x135mm | -12mm | 29.0 | 958MC-79065-12 |
| 18X8.5 | 5x150mm | 35mm | 32.0 | 958MC-88551+35 |
| 18X8.5 | 6x139.7mm (6x5.5") | 35mm | 32.0 | 958MC-88560+35 |
| 18X8.5 | 6x135mm | 35mm | 32.0 | 958MC-88565+35 |
| 18X9 | 5x127mm (5x5") | 18mm | 34.0 | 958MC-89050+18 |
| 18X9 | 5x150mm | 18mm | 34.0 | 958MC-89051+18 |
| 18X9 | 6x139.7mm (6x5.5") | 18mm | 34.0 | 958MC-89060+18 |
| 18X9 | 6x135mm | 18mm | 35.0 | 958MC-89065+18 |
| 18X9 | 8x165.1mm (8x6.5") | 18mm | 35.0 | 958MC-89080+18 |
| 18X9 | 8x170mm | 18mm | 35.0 | 958MC-89081+18 |
| 18X9 | 8x180mm | 18mm | 35.0 | 958MC-89088+18 |
Load rating(s): 2500, 3200, 3650 lb
Hub bore(s): 106.1, 110.5, 130.81, 78.1, 87.1 mm
Fitment shown by bolt pattern; confirm offset and brake clearance for your vehicle.
