- Clean off-road inspired spoke design
- Color matched caps with embossed Raceline logo for a seamless look
- Constructed out of heavy duty A356 aluminum
- Available in Satin Black, Titanium and Machined finish
- Available in 16” to 20” diameters for most 5, 6 and 8 lug trucks and CUV’s
- Passes or exceeds all DOT standard load ratings
- Hub centric fitments available for select vehicles
- Includes a Lifetime Structural Warranty (limitations may apply)
- The Official Wheel of Ultra 4 Racing, NORRA, MidAmerica Outdoors, Southern Rock Racing Series, Nor Cal Rock Racing and more
Sizes & Specifications
| Size | Bolt Pattern | Offset | Weight (lb) | Part # |
|---|---|---|---|---|
| 20X9 | 6x139.7mm (6x5.5") | 0mm | 39.0 | 958B-29060-00 |
| 20X9 | 8x170mm | 0mm | 43.0 | 958B-29081-00 |
| 16X8 | 5x139.7mm (5x5.5") | 0mm | 26.0 | 958B-68055-00 |
| 16X8 | 6x139.7mm (6x5.5") | 0mm | 26.0 | 958B-68060-00 |
| 17X8 | 5x114.3mm (5x4.5") | 30mm | 29.0 | 958B-78012+30 |
| 17X8 | 5x110mm | 30mm | 29.0 | 958B-78021+30 |
| 17X8 | 5x108mm | 30mm | 29.0 | 958B-78023+30 |
| 17X8 | 6x120mm | 30mm | 29.0 | 958B-78062+30 |
| 17X8.5 | 5x127mm (5x5") | 0mm | 29.0 | 958B-78550-00 |
| 17X8.5 | 5x150mm | 35mm | 29.0 | 958B-78551+35 |
| 17X8.5 | 5x150mm | 0mm | 28.0 | 958B-78551-00 |
| 17X8.5 | 6x139.7mm (6x5.5") | 35mm | 29.0 | 958B-78560+35 |
| 17X8.5 | 6x139.7mm (6x5.5") | 0mm | 28.0 | 958B-78560-00 |
| 17X8.5 | 6x135mm | 35mm | 29.0 | 958B-78565+35 |
| 17X8.5 | 6x135mm | 0mm | 29.0 | 958B-78565-00 |
| 17X8.5 | 8x170mm | 0mm | 32.0 | 958B-78581-00 |
| 17X9 | 5x127mm (5x5") | -12mm | 29.0 | 958B-79050-12 |
| 17X9 | 6x139.7mm (6x5.5") | -12mm | 29.0 | 958B-79060-12 |
| 17X9 | 8x170mm | -12mm | 33.0 | 958B-79081-12 |
| 18X8.5 | 5x150mm | 35mm | 32.0 | 958B-88551+35 |
| 18X8.5 | 6x139.7mm (6x5.5") | 35mm | 32.0 | 958B-88560+35 |
| 18X8.5 | 6x135mm | 35mm | 32.0 | 958B-88565+35 |
| 18X9 | 5x127mm (5x5") | 18mm | 34.0 | 958B-89050+18 |
| 18X9 | 5x150mm | 18mm | 34.0 | 958B-89051+18 |
| 18X9 | 6x139.7mm (6x5.5") | 18mm | 34.0 | 958B-89060+18 |
| 18X9 | 6x135mm | 18mm | 35.0 | 958B-89065+18 |
| 18X9 | 8x165.1mm (8x6.5") | 18mm | 35.0 | 958B-89080+18 |
| 18X9 | 8x170mm | 18mm | 35.0 | 958B-89081+18 |
| 18X9 | 8x180mm | 18mm | 35.0 | 958B-89088+18 |
Load rating(s): 2000, 2500, 3200, 3650 lb
Hub bore(s): 106.1, 106.5, 110.5, 130.81, 67.1, 72.62, 78.1, 87.1 mm
Fitment shown by bolt pattern; confirm offset and brake clearance for your vehicle.
